EMUS Cell Module Pair CM10WABPR
$47.00
MPN CM10WABPR
NOTE: Obsolete part, limited quantity available
SKU
CM10WABPR
Description
Emus BMS Cell Modules are the single cell controllers that measure cell voltage and provide means of controlled dissipative balancing. Each Cell Module can also measure its own temperature and, and is equipped with a special serial interface for communication with the main controller.
The 10 W model is a standard solution, designed for convenient wiring and easy installation on higher-capacity prismatic cells. This model also has a possibility to connect an additional external temperature sensor for measuring the cell temperature.
Contains:
EMUS BMS Cell Module 3A type A – 1 pcs.
EMUS BMS Cell Module 3A type-B – 1 pcs
Specifications:
Shunt characteristics:
– RTOT= 1.35Ohm
– PMAX= 10W
Max balancing current: 2,7A (limited by PMAX)
Operating voltage: 2.0V÷4.55V
Operating temperature: -40°C ÷ +80°C
Max balancing current: 2,7A (limited by PMAX)
Operating voltage: 2.0V÷4.55V
Operating temperature: -40°C ÷ +80°C
Voltage measurement accuracy:± 10mV
Temperature measurement accuracy: ± 5°C
Dimensions: 75x30x15 mm
Wire length: 100mm
Mounting hole: M9
Temperature measurement accuracy: ± 5°C
Dimensions: 75x30x15 mm
Wire length: 100mm
Mounting hole: M9
| Battery BMS Configuration | Configurable |
|---|---|
| Battery BMS Type | BMS Parts |
| Country of Manufacture | Lithuania |
