Warner Electric Spring-Set Brake, NEMA 143

The Spring-Set Brake Module is a NEMA 182 TC compatible unit designed to perform holding as well as occasional emergency stopping functions, making it particularly well-suited for motor brake applications. Because it is designed to be mounted on the front of a motor, it is an excellent choice for retrofitting an existing motor, or for use on custom designed machinery.

SSBM Brake torque is developed when springs apply a clamping force between the brake armature and the friciton disc to the end plate. Spring clamping force provides the holding torque of the brake.

Features

• NEMA 182 TC-face compatible mounting
• Performs holding functions with occasional e-stops
• Completely assembled and preburnished at the factory
• Easy to install
• No adjustment required
• High torque, lead-free and asbestos-free friction material
