ME1907 (ME0708) DIY Drive Kit

Motor -

The ME1907 (ME0708) motor has the highest power/weight/dollar ratio available on the market for brushed PM motors. This motor is also a bolt-in replacement for the original Etek motor. The motor runs a little faster than the Perm and Lynch or Lemco motors.

- Brush-type Permanent Magnet DC motor
- Light weight, high efficiency design
- Designed for 24-48VDC battery operated equipment
- 150 amps continuous at 48V (300 amps for 1 minute)
- Capable of 4.8 KW continuous and 15 KW for 1 minute
- Totally open, fan cooled motor
- Runs in either direction

Power: 8 cont-- 15 pk hp Voltage: 48 Volt rated Speed: 3700 rpm @ 48V unloaded Size: 8" OD, 5.5" long (w/o shaft), Shaft: 7/8"x 1-3/4", 3/16" key Weight: 28 lbs.

Controller -

Choose from:
SR48300, SR48400,  SR48500,  SR48600, SR72300, SR72400, SR7500

Throttle -

Choose from:
Curtis style PB-6 or PB-8 Pot Box Throttle, FP-6 style Foot Pedal, Domino Twist Grip throttle, Magura Twist Grip Throttle, 0-5 kΩ Potentiometer Dial with Scale, Single Lever Marine Throttle (right or left hand), Dual Lever Marine Throttle

Contactor -

Contactors (also known as solenoids) are used to connect and disconnect main battery buss power. When it is time to turn your vehicle on or off, the contactor will engage or disengage the power at the flip of a switch. This is very usefull in an emergency situation when main power needs to be turned off quickly and easily. When using an Alltrax controller, the contactor coil Voltage must match the nominal Voltage of your battery pack. The amps should be the same as the controller amps. It is highly recommended that an appropriate pre-charge resistor (included) and a coil spike suppression diode (included) be used with the contactor (supplied in our optional controller wire kit).

Switches -

Choose from:
On/Off Ignition keyswitch with 2 keys, On/Off Toggle Switch - for Run Switch or Personality Mode Switch, Inertia Crash Sensor Switch, Emergency Disconnect Switch

Wire Kit -  Wiring kit specifically designed for this drive kit.

Fuse Block - Matching fuse and holder

Other Options - Motor mounting plate, Reversing Contactor and Reversing Contactor Wire Kit
