EMUS Closed Loop Current Sensor
$135.00
With 100cm Cable, MPN CS020B
SKU
CS020B-C-100
Description
EMUS BMS Closed Loop Dual Range Current Sensor
Connector with control unit 3 ft cable.
EMUS BMS Closed Loop Dual Range Current Sensor is a highly accurate hall-effect current measurement device, specifically designed to be used in EMUS battery management system. The rugged, closed-loop design allows the sensor to be mounted directly on a power cable, witch makes the installation easier, improves calibration stability, and eliminates the heat generation issue at high currents.
Specifications:
Current measurement up to ±1200 A;
Accuracy: 0.5%;
Storage temp.: -40°C ÷ +95°C;?
Operating temp.: –40°C ÷ +80°C;
Supply Voltage(DC): 5V;
Calibrated at factory;
Wire length: 100cm;
Interfaces: Standard;
EMUS BMS Dual Range Current Sensor Connector;
Dimensions: 70 x 60.5 x 25mm;
Hole for cable mounting;
Hole diameter: 18.5 mm.
Standard cable length is 100cm, but the following lengths may be special ordered:
400cm, part # CS020B+400
300cm, part # CS020B+300
150cm, part # CS020B+150
60cm, part # CS020B+60
30cm, part # CS020B+30
18cm, part # CS020B+18
| Battery BMS Configuration | Configurable |
|---|---|
| Battery BMS Type | BMS Parts |
| Country of Manufacture | Lithuania |
